Description

10K Ohm 1/4W 5% Copper Wire Through Hole Resistor

The 10K Ohm 1/4W 5% Copper Wire Through Hole Resistor is a versatile and reliable component commonly used in low-power electronic circuits. It is suitable for general-purpose applications where current regulation, voltage division, and signal conditioning are required.

Specifications:

• Resistance Value: 10,000 ohms (10K ohms)
  This resistor has a resistance of 10,000 ohms, making it ideal for applications that require current limiting, voltage division, or signal conditioning in low-power circuits.

• Power Rating: 1/4 watt (0.25W)
  With a 1/4W power rating, this resistor can safely dissipate up to 0.25W of power, making it suitable for low-voltage circuits, audio systems, and signal processing applications.

• Tolerance: ±5%
  The resistor has a ±5% tolerance, meaning the actual resistance may vary by 5% from the nominal value, ranging from 9,500 ohms to 10,500 ohms. This tolerance range is typical for general-purpose applications where high precision is not critical.

• Mounting Type: Through hole
  This resistor is designed for through-hole mounting, with leads that pass through holes on a PCB, ensuring reliable mechanical and electrical connections.

• Material: Copper Wire
  Constructed from copper wire, this resistor offers good electrical conductivity and is a cost-effective choice for low-power applications.

Key Features:

• 10K Ohms Resistance:
  The 10,000-ohm resistance value is ideal for applications where moderate current regulation, voltage division, or signal conditioning is needed.

• 1/4W Power Rating:
  This resistor can handle up to 0.25W of power dissipation, making it suitable for low-voltage circuits, audio systems, and signal processing applications that don't require high power.

• 5% Tolerance:
  The ±5% tolerance allows for slight variations in resistance, making this resistor suitable for non-precision applications in general electronics, hobby projects, and consumer devices.

• Copper Wire Construction:
  Copper wire construction ensures good electrical conductivity and affordability, making it an ideal choice for budget-friendly designs.

Typical Applications:

1. Current Limiting:
   The 10K-ohm resistor is used in circuits to limit current, such as in LED protection circuits or in applications requiring current control.

2. Voltage Division:
   This resistor is frequently used in voltage divider networks to scale down voltage for specific parts of a circuit, such as sensor circuits, power supplies, and analog systems.

3. Signal Conditioning:
   Ideal for low-power signal processing circuits, the 10K-ohm resistor helps stabilize signal levels, match impedance, and reduce noise in analog systems.

4. Pull-Up/Pull-Down Resistors:
   This resistor is often used in digital circuits to ensure stable voltage levels at logic inputs and prevent floating inputs.

5. RC Circuits:
   The 10K-ohm resistor is suitable for use in RC circuits for timing, filtering, and frequency response applications in low-power designs.

The 10K Ohm 1/4W 5% Copper Wire Through Hole Resistor is an affordable and reliable component that is ideal for low-power and general-purpose electronic applications. Its versatility and cost-effectiveness make it a perfect choice for a wide range of electronic projects.
