Description

The 2M2 Ohm 1/4W 5% Copper Wire Through Hole Resistor is a high-resistance component ideal for applications requiring precise current control and minimal power dissipation. Built with durable copper wire and featuring a compact design, this resistor is perfect for advanced electronic projects and general-purpose use.

Specifications

• Resistance Value: 2,200,000 ohms (2M2 ohms)
  Provides ultra-high resistance, suitable for specialized high-impedance circuit designs.

• Power Rating: 1/4 watt (0.25W)
  Handles up to 0.25W of power dissipation, making it suitable for low-power applications.

• Tolerance: ±5%
  Ensures a resistance range of 2,090,000 ohms to 2,310,000 ohms, accommodating standard tolerance requirements.

• Material: Copper Wire
  Constructed with high-quality copper wire for reliable conductivity and durability.

• Mounting Type: Through Hole
  Allows for straightforward installation on printed circuit boards (PCBs).

Key Features

• Ultra-High Resistance (2M2 Ohm):
  Perfect for high-impedance signal paths, noise suppression, and voltage divider circuits.

• Low Power Dissipation (1/4W):
  Optimized for compact, energy-efficient circuit designs.

• 5% Tolerance:
  Reliable and cost-effective for applications not requiring ultra-high precision.

• Copper Wire Construction:
  Ensures consistent performance, stability, and longevity.

• Through-Hole Design:
  Simplifies soldering and enhances mechanical stability on circuit boards.

Applications

• High-Voltage Circuits:
  Useful in high-impedance circuits where extremely low current is required.

• Noise Suppression:
  Helps reduce unwanted electrical noise in sensitive electronic circuits.

• Voltage Dividers:
  Plays a critical role in creating precise voltage levels for signal processing.

• Input Protection:
  Protects sensitive electronic components, such as microcontrollers and sensors, from overcurrent.

• Leakage Current Limiting:
  Used in applications where minimal current leakage is necessary.

The 2M2 Ohm 1/4W 5% Copper Wire Through Hole Resistor is a reliable and efficient choice for advanced electronic applications. Whether you’re working on high-impedance designs, signal conditioning, or protective circuits, this resistor delivers outstanding performance and stability.
