Description

The 472J 630V 4K7 (0.0047µF) Through-Hole Metallized Film Capacitor (CBB21, P=10MM) is a high-quality, non-polarized capacitor designed for high-voltage and high-frequency applications. This capacitor is constructed using a metallized polypropylene film dielectric, which provides excellent electrical performance, low dielectric loss, and superior insulation resistance.

Key Features:

• Capacitance: 0.0047µF (472J)
• Voltage Rating: 630V DC
• Tolerance: ±5% (J)
• Dielectric Material: Metallized Polypropylene Film
• Package Type: Through-Hole (Radial)
• Lead Spacing (Pitch): 10mm
• Operating Temperature Range: -40°C to +105°C
• Dissipation Factor (DF): Low dissipation factor, ensuring high efficiency
• Self-Healing Property: Extends durability and reliability
• Moisture Resistance: Suitable for use in humid environments

Applications:

• Snubber Circuits: Used in power electronics to suppress voltage transients
• Switching Power Supplies: Ensures stable voltage regulation
• Audio Equipment: Provides filtering and coupling in high-fidelity sound systems
• Industrial and Medical Equipment: Used in precision circuits for signal filtering
• Energy Storage and Pulse Circuits: Effective in high-frequency applications
• Motor Run Applications: Enhances motor efficiency by improving power factor

Advantages:

• High voltage endurance and excellent long-term stability
• High insulation resistance and low ESR (Equivalent Series Resistance)
• Superior self-healing properties enhance reliability
• High frequency handling capability with minimal signal distortion
• Compact radial leaded design for easy PCB mounting

This CBB21 Metallized Film Capacitor is a reliable and efficient choice for demanding applications that require high voltage stability, low loss, and durability in various electronic circuits.
