Description

The 4M7 Ohm 1/8W 5% 0805 SMD Chip Resistor is a high-value resistor ideal for use in modern electronic circuits that require a resistance of 4.7 million ohms (4.7MΩ). Its compact size and reliable performance make it a suitable choice for applications requiring high resistance in tight spaces.

Key Specifications:

• Resistance Value: 4,700,000 Ohms (4.7M Ohms)
• Power Rating: 1/8 Watt (125 mW)
• Tolerance: ±5% (standard accuracy)
• Package Size: 0805 (compact, surface-mount form factor)
• Technology: Thick film

Features:

• Compact Design: The 0805 package size allows for integration into high-density circuit boards, making it ideal for applications where space is at a premium.
• Stable Performance: Provides consistent and reliable resistance across a wide range of environmental conditions, such as temperature and voltage fluctuations, ensuring long-term stability.
• Automation-Compatible: Compatible with automated manufacturing processes like pick-and-place assembly and reflow soldering, making it suitable for large-scale production.
• Durability: Designed to withstand environmental factors such as temperature extremes, humidity, and voltage variations, ensuring reliable operation in challenging conditions.

Applications:

• Current Limiting: Helps protect sensitive components by regulating current flow, preventing damage from excessive current.
• Voltage Dividers: Ideal for voltage scaling or regulation applications in circuits where precise voltage division is required.
• Consumer Electronics: Commonly used in compact devices such as smartphones, wearables, tablets, and other small electronics where space and efficiency are critical.
• Automotive Electronics: Suitable for automotive control circuits, sensor systems, and other applications requiring high precision and long-term reliability.
• IoT and Embedded Systems: Perfect for low-power applications in smart devices and embedded systems, where stable resistance is crucial for optimal performance.

The 4M7 Ohm 1/8W 5% 0805 SMD Chip Resistor is a versatile and reliable component for high-precision applications. Its small size, stable resistance, and durability make it ideal for use in consumer electronics, automotive systems, IoT devices, and embedded applications where high resistance and space efficiency are necessary.
