Description

The 560K Ohm 1/4W 5% Copper Wire Through Hole Resistor is a reliable and cost-effective component designed for low-power electronic applications. It is ideal for applications such as voltage division, current regulation, and signal conditioning where high resistance is required.

Specifications

• Resistance Value: 560,000 ohms (560K ohms)
  Provides a high resistance of 560,000 ohms, suitable for circuits requiring current limitation and signal stabilization.

• Power Rating: 1/4 watt (0.25W)
  Ensures safe dissipation of up to 0.25W of power, making it suitable for low-voltage and signal-level applications.

• Tolerance: ±5%
  The resistance value can vary between 532,000 ohms and 588,000 ohms, meeting the needs of general-purpose applications.

• Mounting Type: Through hole
  Designed for through-hole PCB mounting, providing secure electrical and mechanical connections.

• Material: Copper Wire
  Made from copper wire, ensuring excellent electrical conductivity and durability for various low-power circuits.

Key Features

• 560K Ohms Resistance:
  Provides high resistance for applications like signal attenuation, voltage division, and current control.

• 1/4W Power Rating:
  Suitable for low-power circuits, such as audio systems, sensor circuits, and analog processing designs.

• 5% Tolerance:
  Allows for slight variations in resistance, making it an excellent choice for general-purpose use.

• Copper Wire Construction:
  Offers reliable conductivity and affordability for low-power applications.

Typical Applications

• Current Limiting:
  Used in circuits to control current flow in LEDs, voltage regulators, and motor drivers.

• Voltage Division:
  Ideal for voltage divider networks to adjust voltage levels for analog and digital circuits.

• Signal Conditioning:
  Helps stabilize signal levels, reduce noise, and match impedance in analog systems.

• Pull-Up/Pull-Down Resistors:
  Prevents floating inputs in digital circuits, ensuring stable logic levels.

• RC Circuits:
  Useful in RC circuits for timing, frequency filtering, and signal processing applications.

The 560K Ohm 1/4W 5% Copper Wire Through Hole Resistor is a dependable and versatile component for various electronic applications. Its high resistance value, durability, and cost-effectiveness make it a valuable addition to any project or design.
