Description

This 5.6K Ohm (5,600 Ohm) through-hole resistor is a reliable and versatile component widely used in electronic circuits for current limiting, voltage division, and signal conditioning applications. It is a standard carbon film or metal film resistor, depending on the manufacturer's specification, designed for general-purpose use in hobbyist, educational, and professional electronics projects.

Key Features:

1. Resistance Value: 5.6K Ohm (5,600 Ohm) – Ideal for moderate resistance needs in analog and digital circuits.
2. Power Rating: 1/4 Watt (0.25W) – Sufficient for handling low to medium current and power levels in most applications.
3. Tolerance: ±5% – Ensures stable performance with minimal deviation from the nominal resistance value, making it suitable for general-purpose circuits.
4. Construction: Through-hole design for easy manual soldering and reliable mechanical connections.
5. Material: Typically made of carbon film or metal film, providing low noise and high stability over time.
6. Temperature Range: Operates reliably in a wide range of temperatures, typically -55°C to +155°C.
7. Compact Size: Axial leads with a standard body size, making it easy to integrate into PCBs and breadboards.

Applications:

• Voltage Division: Often used in voltage divider networks for providing reference voltages or scaling signals.
• Current Limiting: Helps protect LEDs, transistors, and other sensitive components by limiting current flow.
• Signal Processing: Used in audio circuits, oscillators, and signal filters.
• Pull-Up or Pull-Down Resistors: Commonly used in microcontroller circuits for setting default logic levels.
• Prototyping and Education: Ideal for breadboard use, circuit experimentation, and learning purposes.

This resistor is color-coded for easy identification, following the industry-standard color bands: Green, Blue, Red, Gold. These indicate its resistance value (5.6K Ohms), multiplier, and tolerance.

Dimensions and Packaging:

• Body Length: Approximately 6.3 mm
• Body Diameter: Approximately 2.3 mm
• Lead Length: Approximately 25 mm (per side)
• Packaging: Available in bulk, tape, or ammo pack for convenience.

With its excellent performance, standard tolerance, and ease of use, the 5.6K Ohm 1/4W through-hole resistor is a fundamental component for any electronics enthusiast or professional engineer.
