Description

The HER 307 High Efficiency Rectifier Diode is designed for modern electronic applications requiring high current handling and efficient rectification. Engineered for reliability and performance, it is perfect for power supplies, motor control circuits, and other high-efficiency rectification needs.

Key Features:

• High Current Rating: Capable of handling up to 3 Amperes (3A), ideal for medium to high-power applications.
• High Voltage Capacity: Withstands peak reverse voltage up to 1,000V, making it suitable for demanding voltage conditions.
• High-Efficiency Design: Minimizes power loss during rectification, ensuring optimal energy efficiency.
• Fast Switching: Provides quick response times, ideal for high-speed circuits and applications requiring rapid switching.
• Durable Through-Hole Design: Ensures strong mechanical connections and robust electrical performance in challenging environments.

Technical Specifications:

• Maximum Recurrent Peak Reverse Voltage (Vrrm): 1,000V
• Forward Voltage Drop (Vf): ≤ 1.1V at 3A
• Maximum Reverse Current (Ir): ≤ 5μA at 25°C
• Operating Temperature Range: -55°C to +150°C
• Package Type: DO-41 (Through Hole)

Applications:

• Power supply circuits
• Voltage regulation in high-power systems
• High-efficiency rectification in switch-mode power supplies
• Freewheeling diodes for motors and inductive loads

Why Choose HER 307?
With its robust 3A current rating and 1,000V voltage handling capacity, the HER 307 is a reliable solution for high-power rectification applications. Its efficiency, fast switching, and durable construction make it a dependable choice for both industrial and consumer electronics, ensuring long-lasting and stable performance
