Description

The IN5818 Schottky Barrier Rectifier Diode is a high-efficiency, reliable diode designed for power rectification in low- to medium-power electronic circuits. With its Schottky barrier technology, this diode features a low forward voltage drop, fast switching characteristics, and high reliability, making it ideal for use in high-frequency, low-voltage applications.

Key Specifications:

• Model: IN5818
• Diode Type: Schottky Barrier Rectifier
• Maximum Average Forward Current (IF): 1A
• Maximum Reverse Voltage (VR): 30V
• Forward Voltage Drop (VF): Low, typically between 0.2V and 0.45V for efficient operation
• Peak Reverse Current (IR): Low, ensuring reliable performance under reverse voltage conditions
• Package Type: Axial Through Hole
• Operating Temperature Range: -55°C to +125°C

Features:

• High Efficiency:
• Low forward voltage drop reduces power loss and increases energy efficiency.
• Ideal for high-frequency and low-voltage applications, improving overall system performance.
• Fast Switching:
• Schottky barrier technology ensures rapid switching speeds, enhancing circuit response times.
• Durability and Reliability:
• Low reverse leakage current ensures consistent, long-term performance.
• High surge current capability for handling transient conditions.
• Compact and Easy Integration:
• Axial through-hole package makes mounting easy on printed circuit boards (PCBs).
• Small form factor suitable for space-constrained applications.

Applications:

• Power Rectification in Consumer Electronics
• Low-Voltage Power Supplies
• Battery-Powered Devices
• DC-DC Converters
• LED Drivers
• Reverse Current Protection in Solar Systems
