Description

The SR3A0 Schottky Barrier Rectifier Diode is a high-efficiency, reliable component designed for power rectification in a variety of electronic applications. Built with Schottky barrier technology, this diode provides low forward voltage drop, fast switching speeds, and excellent reverse voltage protection, making it perfect for high-frequency, high-speed circuits and power conversion applications.

Key Specifications:

• Model: SR3A0
• Diode Type: Schottky Barrier Rectifier
• Maximum Average Forward Current (IF): 3A
• Maximum Reverse Voltage (VR): 200V
• Forward Voltage Drop (VF): Low, typically between 0.7V and 0.85V for efficient operation
• Peak Reverse Current (IR): Low, ensuring stable performance under reverse voltage conditions
• Package Type: Axial Through Hole
• Operating Temperature Range: -55°C to +150°C

Features:

• High Efficiency:
• Low forward voltage drop reduces power loss, resulting in greater overall energy efficiency.
• Excellent for high-frequency and high-speed switching applications.
• Durability and Reliability:
• High surge current capability for heavy-duty applications.
• Strong reverse voltage resistance to ensure long-term reliability and performance.
• Compact and Easy Integration:
• Axial through-hole design simplifies mounting on printed circuit boards (PCBs).
• Compact size allows for use in space-constrained designs.

Applications:

• Power Rectification in Consumer Electronics
• Switching Power Supplies
• Battery Chargers
• LED Lighting Systems
• Solar Panel Reverse Current Protection
• High-Frequency DC-DC Converters
